Maintenance for several important equipments in 1-20tph chicken feed pellet production line

2020-10-20 Back to List

If you are looking for related products or have any other questions, please feel free to contact us.

Contact Us

A 1-20tph complete poultry chicken feed pellet production line is composed of major equipment such as chicken feed grinders, poultry chicken feed pellet making machines, and chicken pellet coolers, as well as many auxiliary equipment. Today we will talk about how to maintain some of the following chicken feed pellet making plant equipments.

Manufacture Suppy for Animal Chicken Cattle Feed Production Line

1. Bucket elevator

(1) Regularly replenish reducer, chain lubricating oil, head and tail bearing grease;

(2) Regularly observe the tightness of the hoist belt. If the belt is loose and slippery, adjust the tail screw to tighten the hoist belt.

(3) Regularly check whether there is any leakage at the inlet of the lower hopper, the flange connection of the hoist, and the head and tail shaft. If there is leakage, apply sealant or replace the seal packing.

(4) Regularly check and replace the damaged bucket on the lifting belt and tighten the bucket screws.

2. Double-shaft paddle chicken feed mixer

(1) Regularly supplement the reducer, chain lubricating oil, main shaft bearing, door opening bearing grease;

(2) The chain should always be slightly tight. Otherwise, the loose chain will easily cause tooth skipping, blade fights and other failures, causing unnecessary losses.

(3) Regularly check and supplement the lubricating oil in the pneumatic system lubricator, check the water collection in the gas-water separator, and ensure that the water level in the tank does not exceed 80%;

(4) Check whether there is any leakage of air (oil) in the pneumatic air pipelines and interfaces. If so, replace the air pipe or re-insert the joint.

(5) Regularly check the mixer rotor and remove the braided belt, nylon thread end and other sundries;

(6) Frequently check whether there is material leakage at the shaft head of the mixer. If there is material leakage, tighten the gland bolts slightly, and replace the packing after the packing is worn out. Frequently check whether there is any leakage at the four corners of the door of the mixer. If there is leakage, adjust the door arm support and tighten the screws.

3. Self-cleaning spiral conveyor

(1) Regularly replenish reducer, chain lubricating oil, head and tail bearing grease;

(2) Frequently check whether there is material leakage at the head and tail shaft. If there is leakage, apply sealant or replace the seal packing;

(3) When changing the chicken feed formula, the cleaning door at the bottom of the auger should be opened, and the residue should be cleaned to prevent cross contamination.

4. Air compressor

(1) Check and replenish the oil level of the air compressor frequently (do not add too much) to maintain good lubrication.

(2) Regularly check and clean the air filter and regularly release sewage and dirt in the air bag.

5. Suction dust removal system

(1) Regularly check the effect of suction and dust removal. If the effect is found to be poor, check whether the pipe is leaking (filling with sealing glue) and whether the cloth bag of the bag filter is seriously blocked (clean the cloth bag regularly, and the new cloth bag may have slight powder leakage Phenomenon);

(2) Regularly check whether there is accumulation of material in the horizontal section of the suction pipe. If there is too much accumulation, clean it up.

(3) Add grease to the air shutter and reducer regularly. If there is abnormal noise in the air shutter and fan, stop the machine and check and solve it before starting the machine.

6. Drum mixer

(1) Always add grease to the rotating system and open gears to ensure good lubrication.

(2) Regularly check whether there is material leakage inside the drum. If there is material leakage or bearing damage, replace it.
