Cost to build a 3-5 tons per hour animal chicken feed manufacturing plant for broiler feed

2021-03-14 Back to List

If you are looking for related products or have any other questions, please feel free to contact us.

Contact Us

Cost to build a 3-5 tons per hour animal chicken feed manufacturing plant for broiler feed is usually between 50000-250000USD.

This complete 3-5 tons per hour animal chicken poultry feed pellet manufacturing plant is specially designed for the production of broiler feed pellets, which can also produce fish, sheep, cattle, rabbits, horses, ducks, geese, pigs and other livestock feed pellets. The broiler feed pellets produced by this low cost high return chicken feed pellet production plant have a diameter between 2mm and 12mm.

how to make chicken feed commercially

1.How to Make High Quality Broiler Feed Pellets?

The broiler chicken feed pellet production process is mainly physical changes. Without changing the nutrients contained in the chicken broiler feed raw materials, the raw materials and additives are mixed together. Because the quality of feed pellets directly affects the animal's feeding status, and ultimately affects the quality of products and the interests of farmers, it is very important for farmers to produce high-quality feed pellets.

2.Components of 3-5tph poultry chicken broiler pellet feed pellet production line

(1)Chicken feed raw materials preparation

Materials for feed can be soybeans, soybean meal,alfalfa, corn, fish meal, amino acid, fusel meal, additives, whey powder, oil, meat and bone meal, corn, sweet sorghum, etc.

(2)Chicken feed grinding process

Chicken feed hammer mill grinder is suitable to grind raw materials into powder with optimal size for best pelletizing effect.

(3)Chicken feed mixing process

By adopting chicken feed mixer, various ingredients can be blended sufficiently to ensure every bite of finished feed pellets can have balanced nutriments.

(4)Chicken feed pelletizing process

Chicken feed pellet milling machine for chicken feed production is the main equipment of the whole 3-5t/h chicken feed pellet production line. Ring die chicken feed pelletizer is more efficient and suitable for high quality chicken feed pellets production in large chicken poultry farms or chicken poultry feed factory. Built-in steam collection conditioner can mix and cook materials fully and uniformly to meet special needs and ensure high quality of final chicken feed pellets.

(5)Chicken feed pellet crumbling process

Different poultry, livestock or aquatic feed pellets are with different sizes. Some big ones should be crushed into small ones. Roll type feed pellet crumbler is just the equipment for feed pellet crushing. Double-roll feed pellet crumbler is suitable for crushing poultry feed, such as chicken feed, duck feed and goose feed etc. Three-roll chicken feed pellet crumbler is suitable to crush aquatic feed including fish feed and shrimp feed etc.

(6)Chicken feed pellet cooling process

After this process, you can get finished chicken feed pellets with rich nutrition, good palatability and high digestibility. Chicken feed pellets cooler and packing machine are available for your choice to get top chicken feed pellets making experience. Moreover, to cater for the special requirements of our clients, we can also customize different capacity chicken poultry feed pellets processing plant.

manufacturing machines for chicken feed

3.Advantages of 3-5t/h broiler chicken feed pellet producing line

(1)Excellent manufacturing: All chicken feed producing equipments have been strictly developed and manufactured to ensure high quality.

(2)Easy installation and operation: This 3-5tph broiler chicken feed line takes only a few days to assemble and install all the parts. You don't need a technician or any qualified person, you can do it! Operation is as simple as installation.

(3)Low investment: Because of its small size, compact structure, and low power consumption, a small investment is enough for you to buy this 30t/h commercial chicken broiler feed pellet plant.

(4)Low Production Cost: Only 1 or 2 workers are enough to make the whole 3-5t/h chicken feed production factory work. Less labor, less cost, so it greatly expands your net profit.

(5)Wide application: You can choose it for making many kinds of animal feeds, such as cattle, dairy cow, goat, sheep, horse, pig, chicken, broiler, duck, rabbit, fish, goose, etc.

4.Benefits of Build Your Own Chicken Feed Pelletizing Plant With 3-5TPH Capacity

(1)From the perspective of the animal poultry chicken feed production equipment manufacturer, the benefits of chicken broiler feed pellets include reduced separation of mixed feed, increased bulk specific gravity, reduced dust content, and improved operating characteristics.

(2)For those who produce their own animal feed, compared to buying chicken feed pellets from other chicken feed manufacturers, it will save a lot of cost.

5.Equipment needed to start a 3-5t/h broiler chicken poultry feed mill

Item Name Model Power (KW)
Part 1. Raw material receiving& crushing system
1-110 Impeller speed regulating Feeder SWLY60 1.10
1-111 hammer mill for grinding chicken poultry feeds SFSP66*60 55.0
1-116 Wind-shielding Screw conveyor TLSB20 2.20
Part 2. Mixing System
2-203 Powder Screener SCQZ60 5.5
2-207 Feeder for additive
2-208 Mixer machine for mixing chicken feed SLHS1.0 11
2-210 Scraper Conveyor TGSU20 3
Part 3. pelleting system
3-308 Chicken Feed Pellet Manufacturing Machine SZLH350 55
3-310 Pellet Cooler SKLN3 1.50
3-311 Pellet Crumbler SSLG15*150 11.0
Part 4. Packing system
4-401 Bucket elevator TDTG36/18 3.00
4-402 Rotary Screener SFJH80*2d 2.20
4-409 Auto Packing Scale 10-50KG 1.50
4-410 Stitch conveyor   1.50
Part 5. Auxiliary Equipment System
5-506 Steam Supplying System
5-507 Oil adding System   2.2
5-508 Oil Adding Tube
5-509 Calabash Crane   3.0
Contact Richi Machinery to Get Complete Business Plan For Setting Up Chicken Feed Production Plant

what should i know before coming up with my own 3-5t/h chicken feed production plant

6.RICHI best design low cost 3-5t/h feed pellet lines for poultry chicken broilers

(1)3-5T/H Chicken Feed Pellet Production Line In Zimbabwe

(2)3-5T/H Animal Chicken Feed Pelleting Line(Pelletizing and Cooling System) In Uzbekistan

(3)3-5T/H chicken feed pellet making lines in Algeria

(4)3-5T/H chicken poultry feed pellet processing line in Uzbekistan

(5)3-5T/H Poultry feed pellet manufacturing  line for chicken in Senegal

(6)3-5T/H Poultry Animal Chicken Feed Making Factory In Uzbekistan

(7)3-5T/H Poultry Chicken Broiler Feed Pellet Manufacturing Plant In Uzbekistan

(8)Complete 3-5 Ton Per Hour Broiler Chicken Feed Pelleting Plant In Uzbekistan

(9)3-4 Ton per hour automatic chicken animal feed pellet making plant project in Colombia
