(1)Materials Receiving and Crushing System For 5T/H Chicken Broiler Pellet Feed Making Plant
Equipments related in the raw material receiving and crushing system of animal feed pellet production line is listed below.
Cost of this Part: $7000 Approx.
|Multifunctional chicken feed grinding machine||9FQ50-40||1||37kw||Hammer mill, it can realize different finess by change the screen.|
|Draught fan||4-72No4A||1||5.5kw||It is checked by the dynamic balance, the running is stable with low noise.|
(2)Mixing System For 5T/H Chicken Broiler Pellet Feed Production Plant
Equipments related in the fodder raw materials mixing system of 5tph chicken feed pellet production is listed below.
Cost of this Part: $8000 Approx.
|Corn grinder crushing machine for chicken||SFL20||1||15kw||It adopts second crushing technology, and widens the screen pieces at 360°,the inside screen has a large area, the rotor can make the chamber produce positive pressure. The materials smaller than the screen hole can be discharged quickly, the materials are crushed evenly.|
|Pneumatic gate valve||DN50||1|
|Single-shaft chicken feed mixing machine||SHW2.5||1||15||CV<7%, the mixing time is 5 minutes.|
(3)Pelletizing System , Cooling System and Packing System For 5T/H Chicken Broiler Pellet Feed Plant
This followings are related equipments in broiler chicken animal feed pelletizing and final pellets packaging system.
Cost of this Part: $40000 Approx.
|Bucket elevator||TDTG36-23||1||1.5kw||High strength of plastic winnowing pan. The buttom pulley is reseau shape, which won't be stained with materials. The machine cylinder is made of 2mm of plate.Siemens motor.|
|Feed Pellet Manufacturing Machine for Chicken||SZLH320||1||37kw||Gear drive, gear grinding technique, the moding box adopts stainless steel materials, SKF imported bearing, imported oil seal, the pelletizing efficiency is higher about 15% than the belt pellet mill, it is equipped with Siemens motor.|
|Bucket elevator||TDTG36-23||1||1.5kw||High strength of plastic winnowing pan. The buttom pulley is reseau shape, which won't be stained with materials. The machine cylinder is made of 2mm of plate. Siemens motor.|
|Counterflow cooling machine||SKLN11×11||1||1.5kw||Counter flow cooling, pellet cooling is even, and it won't burst. The cooling time and filling content can be adjusted. The discharging is fluent and there is no residues.|
|Draught fan||4-72No4A||1||11kw||It is checked by the dynamic balance, the running is stable with low noise.|
|Cyclone||SK90||1||The material adopts 3mm of carbon steel,and the Flange adopts 5mm of carbon steel.|
|Screening machine||1||No material deposition, no cross contamination, low noise, high efficiency.|
